Sliding Door Lock- FD60

This sliding door look is recessed into the door and the deadbolt is operated by a privacy snib from the inside and emergency release from the outside. These locks are usually installed on doors that lead into a cloakroom, bathroom or WC. The privacy snib and emergency release will need to be compatible with a 5mm square spindle.

These locks are not compatible with dustboxes or rebate kits.

Certified for FD60 rated fire doors.

Minimum door thickness for these locks is 44mm and the maximum, as standard, is 54mm

Includes:

• Lock case (The actual lock)

• Forend (Plate that goes over the end of the lock)

• Strike plate (Plate that is fitted to the frame)

• Intumescent sleeve for fire doors

• Fixing pack

BRANDING

BF - branded forend plate with small JG logo, as per product images

UF - plain, unbranded forend plate

SPRINGING

HS - heavy sprung, recommended for use with heavy levers or lever handles being installed without our sprung bearing rose

MS - medium sprung, recommended for use with levers handles being installed with our sprung bearing rose

LS - light sprung, recommended for use with door knobs
